| TECHNICAL CHARACTERISTICS |
| Power supply voltage |
380 [V] – 60 [Hz] |
| Installed power |
200 [KW] |
| Air |
Consumption (filtered, dried, no water, no oil) |
0.5 [m3/min] |
| Operational pressure (constant) |
0.6Mpa |
| Water |
Consumption (clean, filtered, no residues, no calcium, no deposits) |
30 [m3/hr] |
| Min. pressure (constant) |
0.3Mpa |
| Max. temperature at inlet |
30 [°C] |
| Ambient conditions |
Temperature |
0 – 40 [°C] |
| Altitude |
< 1000 [m.a.s.l.] |
| MATERIAL CHARACTERISTICS |
| Raw material type |
Hot rolled low carbon wire rod |
| Coil dimension |
Inner diameter |
Min 850 [mm] |
| Outer diameter |
Max 1250 [mm] |
| Height |
2500 [mm] |
| Coil weight |
Max 2,500 [Kg] |
| Wire rod inlet tensile stress |
Min 440 [N/mm2] |
| Wire rod inlet diameter |
5.5 – 8.0 [mm] |
| FINISHED PRODUCTS CHARACTERISTICS |
| Production rate |
Max 6 [m/sec] |
| Finished products type |
Cold drawing wire coil |
| Coil dimension |
Inner diameter |
Min 500 [mm] |
| Outer diameter |
Max 1100 [mm] |
| Height |
490 [mm] |
| Coil weight |
Max 1,500 [Kg] |
| Wire rod outlet tensile stress |
Min 550 [N/mm2] |
| Wire rod outlet diameter |
3.5 – 6 [mm] |
